* 1/4" DSP B/W, 92 degree of view, 3.6mm Auto-Iris Lens, Audio Not Available
* Security Camera Features:
* Fully functioning plug and play surveillance system.
* High quality CCD camera built inside.
* Camera is virtually hidden.
* 8 channel scroll selectable receiver.
* Black and white
* 12VDC Power
Specifications:
* Image Sensor 1/4" DSP B/W sharp
* Effective Pixels EIA: 512(H)X492(V)
* Scanning System EIA: 525 Lines
* H Resolution 380 TV Lines
* Synchronizing system Internal
* Scanning system 2:1 interlaced
* Video output 1.0Vp-p Composite. 75 Ohms
* S/N ratio More than 48 dB (AGC Off)`
* Min. Illumination 0.05 Lux at F2.0
* Shutter speed EIA: 1/60-1/100,000 sec
* Gamma correction Y=0.45
* Gain Control Automatic
* MTBF 80,000 hours
* Power source DC12V(Tolerance:9V-15V0
* Operating current 100mA w/regulated power in
* Lens 3.6mm Fixed iris (92 degree AOV)
* Operating temperature: 14degreeF ~ 122degreeF (-10degreeC~50 degree C) Humidity Within 90% RH
* Output Terminal 4 foot BNC-Female for video, DC jack-Male for power
* Weight (approx.g) 30
* White Balance Standard 2100 K ~ 8200K Auto
